Mazzella 7-Part™ Wire Rope Sling

The Mazzella 7-Part™ Wire Rope Sling Is Ergonomic

Our customers tell us the Mazzella 7-Part™ Wire Rope Sling is their sling of choice. For more than 65 years, Mazzella has constructed this sling from one continuous piece of wire rope.

This sling is ultra-flexible and user friendly. It has been redesigned for higher capacities.

Mazzella Logo

Description

The Mazzella 7-Part™ Wire Rope Sling:

  • Saves money—stays manageable longer
  • Saves time—easiest wire rope sling in the world to rig
  • Saves resources—easier to handle
  • Improves inspection—the end user is able to inspect the uncovered eyes
  • Quick-ship—popular sizes available from stock

The small diameter slings are galvanized for clean handling, and are a favorite for the maintenance department. For your large lifts, the Mazzella 7-Part™ Wire Rope Sling is a more manageable sling at a cost savings vs. standard wire rope slings.




IWRC EIP Flemish Mechanical Spliced (6 x 19 & 6 x 36 Class)

The Mazzella 7-PartTM Wire Rope Sling Specs

* Sling capacities for rope diameters 1/8″ through 5/16″ are based on using 7 x 19 G.A.C. wire rope.

** Sling Angles in this catalog depart from the traditional method of vertical angles measured at the sling hook. It has long been the opinion of sling users that it is easier to measure a sling angle relative to the ground or horizontal. The method is the same whichever angle is used. When the horizontal angle is used you must use the trigonometric side of the horizontal angle. When the vertical angle is used you must use the trigonometric cosine of the vertical angle.

Rated capacities based on pin diameter no larger than the natural eye width or no less than 5 times the component rope diameter.

Rated capacity basket hitch based on D/d ratio in the body of 10 times the component rope diameter.

Rated capacities based on design factor of 5 when new.

Horizontal sling angles less than 30° degrees shall not be used.



Brand

Mazzella

Mazzella Companies employs over 800 individuals at more than 30 locations in North America.
Mazzella is one of the largest independently-owned companies in the overhead lifting and rigging industries and is a manufacturer and distributor of a wide range of lifting products for industrial, commercial and specialty applications. In addition, Mazzella is a leader in providing overhead cranes, overhead crane services, material handling, specialty machinery, and warehousing solutions. Some of the major markets we serve are: Steel, Construction, Energy, Vehicle and Durable Goods, Ship Building / Repair, and Mining. Our diverse portfolio also includes Sheffield Metals, a manufacturer and distributor of coated bare metal products for engineered metal roof and wall systems, and New Tech Machinery, a manufacturer of portable roof panel, wall panel and gutter machines.
Mazzella Logo


All product warnings: Warnings Page
