Does OSHA Require a Hook with a Safety Latch for an Overhead Lift?

When deciding on whether to use a hook latch or not, careful consideration must be given to the specific lifting application.

Mike Close


The use of latches on hooks is a topic that is constantly up for debate in the lifting and rigging industries. While some people argue that hook latches are always required and should always be utilized, others argue that latches are not required.

Unfortunately, there are limited explanations or interpretations of when a latch on a hook must be utilized. With no clear industry-wide rules on whether a hook latch is required on a crane hook or a sling hook, the decision is ultimately left up to the owner or end-user. When deciding on whether to use a latch or not, careful consideration must be given to the specific lifting application.

At Mazzella, quality and safety are cornerstones of our success. We provide our customers with user/operator training, rigging inspection and repair services, and we also make and distribute wire rope, chain slings, synthetic slings, and rigging hardware.

Our goal for this article is to provide you with the information that is available regarding the use of hook latches, as well as some interpretations that Occupational Safety and Health Administration (OSHA) has provided in response to questions that have been asked of them.

Below are four such interpretations pertaining to the use of latches on hooks. For clarity’s sake when reading the OSHA interpretations below, OSHA provides definitions for the terms “shall” and “should” as follows:

  • “Shall” means mandatory
  • “Should” means recommended

Please Note: As a company, we use the terms “hook latch” or “hooks with latches.” OSHA uses the term “safety latches,” so for the purpose of this article, we may use that term to summarize OSHA’s interpretations or standards. However, the term “safety” implies that the user will always be safe when lifting a load using a hook with a latch.

It is always the responsibility of the end user or other designated or qualified person to inspect their rigging equipment and make sure that it is in proper working condition and rated for the specific task, prior to performing a lift.

OSHA Interpretation #1 – March 2004

Does OSHA Require a Hook with a Safety Latch for an Overhead Lift: Hooks with Latch Kit

Question: Is it mandatory for large crane hooks to have safety latches on them? If so, are older hooks without them “grandfathered”?

OSHA Response: OSHA requirements for a safety latch on hooks do not depend on the size of the hook but rather the activity for which the hook is being used. Safety latches on hooks are required in two instances:

1. Personnel Platforms

Section 1926.550(g)(4)(iv)(B) states: Hooks on overhaul ball assemblies, lower load blocks, or other attachment assemblies shall be of a type that can be closed and locked, eliminating the hook throat opening. Alternatively, an alloy anchor type shackle with a bolt, nut and retaining pin may be used.

This provision is intended to prevent personnel platforms from falling as a result of becoming accidentally unfastened from the hook.

2. Working Under the Load

Section 1926.753(d) prohibits: Workers engaged in steel erection activities from being directly under a suspended load, with some exceptions. Where those exceptions apply (i.e., where workers are engaged in the initial connection of steel or employees are unhooking the load), specific criteria apply. One such criterion is the requirement for safety latches.

Section 1926.753(d)(2)(ii) states:

  • Hooks with self-closing safety latches or their equivalent shall be used to prevent components from slipping out of the hook
  • This provision was intended to prevent the components from becoming accidentally unfastened from the hook and falling on the worker below. The preamble to the proposed rule explained that an “equivalent” device would include:
    • A hook with another type of closing device, i.e., a hook with a spring-loaded gate or another type of safety hook that would provide the same level of safety as a safety hook with a self-closing latch.

Neither the personnel platform nor the steel erection/working under load requirement has an exception for large hooks – the requirements apply irrespective of the size of the hook. Also, there is no “grandfather” exception for older hooks without safety latches.

Summary:

  • OSHA 1926.550(g)(4)(iv)(B) states that requirements for latches on hooks are not mitigated by the size of the hook or “grandfathered” for older hooks without safety latches
  • Hooks with latches are required when used in conjunction with a personnel platform, overhaul ball assembly, lower load block, or other attachment assemblies
  • OSHA 1926.753(d) prohibits steel erectors from working directly underneath a suspended load unless self-closing latches or their equivalent are used to prevent components from becoming accidentally unfastened from the hook and falling on workers below.
  • Exceptions may apply to employees engaged in the initial connection of steel or employees who may be unhooking the load
  • Equivalent device would be a hook with a spring-loaded gate or another type of hook that would provide the same level of safety as a hook with a closing latch

OSHA Interpretation #2 – January 2006

Does OSHA Require a Hook with a Safety Latch for an Overhead Lift: Sling Hooks

Question: Does OSHA require the use of latches on hooks on slings?

OSHA Response: Whether OSHA requires a safety latch on a sling hook depends on the activity for which the sling is being used.

You are correct that although the standard for slings provides that “slings shall be securely attached to their loads,” the section does not explicitly require that the hook is equipped with a safety latch (29 CFR §1910.184(c)(6)).

Use of a hook with a safety latch would, of course, be one way of securely attaching a sling to its load. As you also noted, OSHA’s standard for derricks does include an explicit requirement for latch type hooks: “Hooks shall meet the manufacturer’s recommendations…and safety latch type hooks shall be used wherever possible.” (29 CFR §1910.181(j)(2)(i) and 1910.181(j)(2)(ii)).

The standard defines “safety hook” as “a hook with a latch to prevent slings or load from accidentally slipping off the hook.” (29 CFR §1910.181(a)(29)).

We would also call your attention to the following provisions in OSHA’s maritime and construction standards: 29 CFR Part 1917, Marine Terminals, at 29 CFR §1917.45(e)(2) (“Crane hooks shall be latched or otherwise secured to prevent accidental load disengagement.”); 29 CFR Part 1918, Safety and Health Regulations for Longshoring, at 29 CFR §1918.66(e)(2) (“Crane hooks shall be latched or otherwise secured to prevent accidental load disengagement.”), and at §1918.81(b) (“Cargo handling bridles, such as pallet bridles, which are to remain attached to the hoisting gear while hoisting successive drafts, shall be attached by shackles, or other positive means shall be taken to prevent them from being accidentally disengaged from the cargo hook.”); and 29 CFR Part 1926, Safety and Health Regulations for Construction, at 29 CFR §1926.753(d)(2)(ii) (in specified situations, “Hooks with self-closing safety latches or their equivalent shall be used to prevent components from slipping out of the hook…”).

The Occupational Safety and Health Act of 1970 also contemplates that, in the absence of a specific OSHA standard addressing a hazard, employers are required, by the statute’s “General Duty Clause” (Section 5(a)(1)), to protect employees from serious recognized hazards. OSHA often considers the provisions of industry consensus standards, such as those published by the American National Standards Institute (ANSI) or the American Society of Mechanical Engineers (ASME), when evaluating whether a hazard is “recognized” and whether there is a feasible means of abating that hazard. One such provision that OSHA would consider is Section 2-1.14.5, Hooks, of ASME 30.2-2001, Overhead and Gantry Cranes: “Latch-equipped hooks shall be used unless the application makes the use of the latch impractical or unnecessary.”

Summary:

  • OSHA states that “slings shall be securely attached to their loads.” They go on to explain that this does not explicitly say that the hook needs to be equipped with a latch, however, they do note that the use of a hook with a latch is one way to securely attach a sling to its load.
  • OSHA’s standards for derricks does include an explicit requirement for latch-type hooks: “Hooks shall meet the manufacturer’s recommendations…and safety latch type hooks shall be used wherever possible.
    • A “safety hook” is defined as “a hook with a latch to prevent slings or loads from accidentally slipping off of the hook.”
  • OSHA has provisions requiring the use of hook latches for maritime and construction applications:
    • Crane hooks shall be latched or otherwise secured to prevent accidental load disengagement. [Marine Terminals – 29 CFR §1917.45(e)(2)]
    • Crane hooks shall be latched or otherwise secured to prevent accidental load disengagement. [Longshoring – 29 CFR §1918.66(e)(2)]
    • Cargo handling bridles, such as pallet bridles, which are to remain attached to the hoisting gear while hoisting successive drafts, shall be attached by shackles, or other positive means shall be taken to prevent them from being accidentally disengaged from the cargo hook. [Longshoring – §1918.81(b)].
  • Hooks with self-closing safety latches or their equivalent shall be used to prevent components from slipping out of the hook… [Construction – §1926.753(d)(2)(ii)].
  • OSHA states that in the absence of a specific OSHA standard addressing a hazard, employers are required, by the statute’s “General Duty Clause” (Section 5(a)(1)), to protect employees from serious recognized hazards.
    • OSHA often considers the provisions of other industry standards, such as those by ANSI or ASME, when evaluations whether a hazard is “recognized” and whether there are feasible means of reducing that hazard.
    • ASME 30.2-2011 Overhead and Gantry Cranes states: “Latch-equipped hooks shall be used unless the applications makes the use of the latch impractical or unnecessary.”

site assessment osha compliance

OSHA Interpretation #3 – March 1976

Does OSHA Require a Hook with a Safety Latch for an Overhead Lift: Hooks On Chain

Question: …requesting clarification of the OSHA requirement for safety latches on lifting hooks. In March 1976, OSHA responded to a letter requesting clarification regarding latches.

OSHA Response: The requirement for safety latches (AKA throat latches) is only specified in OSHA 1910.181(j)(2)(ii), which states that “Safety latch type hooks shall be used wherever possible.”

OSHA compliance officers may use the OSHA general duty clause identified as paragraph 5(a)(1) of the Williams-Steiger Act whenever a hazard is created by a hoisting operation where the hoist hook is not provided with a throat latch. The compliance officer may then support the 5(a)(1) citation by calling attention to 1910.181.(j)(2)(ii).

A second alternative would be to cite the “General Duty Clause” 5(a)(1) and support it with the industry practice where the use of safety or throat latches is fairly common.

Summary:

  • OSHA 1910.181(j)(2)(ii) states that “safety latch type hooks shall be used wherever possible.”
  • OSHA may refer to the “General Duty Clause” whenever a hazard is created by a hoisting operation where a hook without a latch is used.

OSHA Interpretation #4 – December 1983

Does OSHA Require a Hook with a Safety Latch for an Overhead Lift: Crane Hook with Latch

Question: …requesting an interpretation of the term “closed hook” in OSHA Instruction STD 1-11.2B, paragraph F.2.c.

OSHA Response: The Lifting Bridle Requirements in the above-referenced instruction refer to working platforms suspended from cranes used to hoist and suspend employees in unique work situations, when such action would result in the least hazardous exposure to employees. In order to permit employers to use crane-suspended work platforms, OSHA has determined that certain conditions must be met to ensure a greater degree of protection for employees. The lifting bridle on working platforms suspended from cranes for employee access or egress must be secured by a shackle or attached by a closed hook which cannot open due to the load position in the hook. Experience has shown that spring loaded safety latches can open with certain changes in the load position in the hook. Therefore, spring loaded safety latched hooks are not considered “closed hooks” for hoisting and suspending employees on a work platform.

There are available and in use hooks that can be closed and locked which will not allow the load to escape should the load position shift in the hook. Use of this type of hook or of a shackle will ensure controlled conditions to permit employee hoisting.

The requirements set forth in OSHA Instruction STD 1-11.2B are designed to further the protection of employees working on platforms suspended from cranes, and the proposed standard 29 CFR 1926.550(g) will reflect these attachment requirements.

Summary:

  • The lifting bridle on working platforms suspended from cranes for employee access must be secured by a shackle or attached by a closed hook which cannot open due to the load position in the hook.
    • Spring-loaded latches can open with certain changes in the load position in the hook, and are not considered “closed hooks” for hoisting and suspending employees on a work platform.
    • A hook that can be closed and locked will not allow the load to escape should the load position shift in the hook. Use of this type of hook or of a shackle will ensure controlled conditions to permit employee hoisting.

Mazzella’s Best Practice for Using Latches on Hooks

Does OSHA Require a Hook with a Safety Latch for an Overhead Lift: Wire Rope and Boom Hooks

When we train our employees and inspectors on the use of hook latches, we take all of the following into consideration:

  • Any hook that is designed to have a latch, should have the latch installed
  • New slings are sold with the latch installed unless the customer requests no latch
  • If customers make an inquiry about the use of a latch on a hook, we may recommend for them to consider several OSHA standard interpretations, among them the following:
    • The Occupational Safety and Health Act of 1970 also contemplates that, in the absence of a specific OSHA standard addressing a hazard, employers are required, by the statute’s “General Duty Clause” (Section 5(a)(1)), to protect employees from serious recognized hazards. OSHA often considers the provisions of industry consensus standards, such as those published by the American National Standards Institute (ANSI) or the American Society of Mechanical Engineers (ASME), when evaluating whether a hazard is “recognized” and whether there is a feasible means of abating that hazard.
    • One such provision that OSHA would consider is Section 2-1.14.5, Hooks, of ASME 30.2- 2001, Overhead and Gantry Cranes: “Latch-equipped hooks shall be used unless the application makes the use of the latch impractical or unnecessary.”
    • Or the following OSHA standard interpretation may be referenced: The requirement for safety latches (AKA throat latches) is only specified in OSHA 1910.181(j)(2)(ii), which states that “Safety latch type hooks shall be used wherever possible.”
    • Or the following OSHA standard interpretation may be referenced: Whether OSHA requires a safety latch on a sling hook depends on the activity for which the sling is being used.

We hope that this information was helpful. While there still are no clear-cut guidelines on the use of hook latches, Mazzella’s recommendation is that they should be used. We advise that the end user must evaluate the work activity with regards to the safety of their employees. If the activity makes the use of the latch impractical, unnecessary, or more dangerous, then the end user may choose to eliminate the latch. It is also recommended that each lifting activity is considered independently as far as the use of a hook latch is concerned.

If you have any questions regarding the use of hooks with latches, please contact us and one of our lifting specialists or inspectors can schedule a time to come to your facility for a consultation and recommendation.
