Description
Features and Benefits:
- Low stretch
- High strength
- Soft hand
- Torque free
- Excellent wet strength
- Meets MIL-DTL-24677B
Applications:
- Winch lines
- Utility pulling lines
- Towing lines
- Offshore anchor and lifting lines
- Arborist bull ropes
- Theatrical rigging lines
Certifications:
- ABS
- DNV-GL
| Nominal Diameter (inches) | Size (circ in.) | Approximate Weight (lbs/100ft) | Minimum Tensile Strength Spliced Rope (lbs) | Minimum Tensile Strength ISO Unspliced Rope (lbs) |
|---|---|---|---|---|
| 1/4 | 3/4 | 2.4 | 2,400 | 2,700 |
| 5/16 | 1 | 3.6 | 3,600 | 4,000 |
| 3/8 | 1-1/8 | 4.8 | 4,800 | 5,300 |
| 7/16 | 1-1/4 | 6.3 | 6,300 | 7,000 |
| 1/2 | 1-1/2 | 8.6 | 8,400 | 9,300 |
| 9/16 | 1-3/4 | 11.1 | 10,750 | 11,900 |
ABS and DNV Type Approved Sizes | ||||
| 5/8 | 2 | 13.1 | 12,300 | 13,700 |
| 3/4 | 2-1/4 | 18.8 | 17,400 | 19,300 |
| 7/8 | 2-3/4 | 25.6 | 24,000 | 26,700 |
| 1 | 3 | 33.5 | 31,200 | 34,700 |
| 1-1/8 | 3-1/2 | 42.4 | 39,500 | 43,900 |
| 1-1/4 | 3-3/4 | 52.3 | 48,100 | 53,400 |
| 1-5/16 | 4 | 57.8 | 53,100 | 59,000 |
| 1-1/2 | 4-1/2 | 75.4 | 64,300 | 71,400 |
| 1-5/8 | 5 | 88.2 | 77,800 | 86,400 |
| 1-3/4 | 5-1/2 | 103.0 | 89,200 | 99,100 |
| 2 | 6 | 134.0 | 110,000 | 122,200 |
| 2-1/8 | 6-1/2 | 151.0 | 124,000 | 137,800 |
| 2-1/4 | 7 | 169.0 | 141,000 | 156,700 |
| 2-1/2 | 7-1/2 | 209.0 | 170,000 | 188,900 |
| 2-5/8 | 8 | 231.0 | 186,000 | 206,700 |
| 2-3/4 | 8-1/2 | 265.0 | 206,000 | 228,900 |
| 3 | 9 | 301.0 | 237,000 | 263,300 |
| 3-1/4 | 10 | 354.0 | 292,000 | 324,400 |
| 3-5/8 | 11 | 440.0 | 348,000 | 386,700 |
| 4 | 12 | 536.0 | 401,000 | 445,600 |
| 4-1/4 | 13 | 605.0 | 454,000 | 504,400 |
Tensile Strengths are determined in accordance with Cordage Institute 1500, Test Methods for Fiber Rope. Weights are calculated at linear density under standard preload (200d2) plus 4%. See reverse side for application and safety information.
Technical Information
Specific gravity: 1.38*
Melting point: 482°F (250°C)
Critical temperature: 350°F (177°C)
Coefficient of friction: 0.12–0.15*
Elongation at break: 15–20%
Fiber water absorption: 0–1%
UV resistance: excellent
Wet abrasion: excellent
Dry abrasion: excellent
* Value based on data supplied by the fiber manufacturer for new, dry fiber
